• Fits wide range of beam sizes for maximum versatility
• Steel plate side frames
• Steel spur gearing for optimum strength and smooth operation
• Universal tread hardened trackwheels that operate on standard S-beams or flat flanged beams
• Lubricated double-row ball bearings for high efficiency and low maintenance
• Metric rated
• For use with lug suspended Lodestar electric chain hoists
• Gear train lubricated with non-oxidizing grease
• Precision machined and hardened lift-wheel with hardened chain guides for precise chain lift-wheel fit
• Gearing designed for exceptionally long life and quiet operation
• Pack of 1 EA
• Manufacturer part number: 9318
• UPC Code: 43927693184

Specifications:

• Beam Height [Max] = 15 in
• Beam Height [Min] = 8 in
• Control Type = On/Off
• Corner Radius [Min] = 30 in
• Frequency [Nom] = 60 Hz
• Horizontal Speed [Nom] = 30 ft/min
• Load Cap. [Max] = 3 tons
• Phase = Single
• Power Cap. [Max] = 60 W
• Power Cap. [Nom] = 1/4 hp
• Power Source = Electric
• Type = Powered Trolley
• Voltage [Nom] = 115 VAC
• Wheel Diam [Nom] = 4 in
• Wheel Flange Width [Max] = 5 5/8 in
• Wheel Flange Width [Min] = 4 in
• Wt. = 119 lb
• This is a normal stocking item.
